Schneider ATV310HD18N4E Inverter | Specifications, Features & Applications

Schneider ATV310HD18N4E is a high-performance variable speed drive designed for controlling three-phase asynchronous motors, delivering reliable operation, energy efficiency, and precise motor control for a wide range of industrial applications.

ATCS for Control Systems is an authorized industrial distributor of Schneider Electric in Egypt, providing genuine products, technical support, and professional automation solutions — learn more through our official website  ATCS for Control Systems

What Is Schneider ATV310HD18N4E?

Schneider ATV310HD18N4E is a variable speed drive developed for simple and medium-duty motor control applications. It is optimized for both constant torque and variable torque loads, making it suitable for machinery that requires dependable speed control with minimal configuration.

The drive operates on a three-phase power supply (380–460V AC) and supports heavy-duty industrial operation with excellent torque performance and robust protection features.

Key Technical Specifications of Schneider ATV310HD18N4E

Electrical Specifications

• Supply voltage: 380–460 V AC (Three Phase)

• Motor power:

  • 18.5 kW (25 HP) – Heavy Duty

  • 22 kW (30 HP) – Normal Duty

• Output frequency range: 0.5 – 400 Hz

• Switching frequency: 4 kHz (adjustable up to 12 kHz)

• Output voltage: Three-phase 380–460 V

Motor Control and Performance

Control Modes

Schneider ATV310HD18N4E supports multiple motor control modes:

• V/F control

• Quadratic V/F for pumps and fans

• Sensorless Vector Control (SVC)

These modes ensure smooth motor operation, accurate speed control, and optimized torque across different load conditions.

Torque and Braking Performance

• Speed range: 1:20

• Transient over-torque capability: up to 200%

• Braking torque:

  • Up to 150% with braking resistor

  • Up to 70% without braking resistor

• DC injection braking for smooth stopping

Communication and Integration Capabilities

Built-in Modbus Communication

Schneider ATV310HD18N4E includes integrated Modbus RTU communication, enabling seamless integration with PLCs, HMIs, and SCADA systems.

• Protocol: Modbus RTU

• Interface: RS-485 (2-wire)

• Connector: RJ45

• Transmission speeds: 4.8 to 38.4 kbps

• Address range: 1–247

This makes the inverter ideal for industrial automation and monitoring applications.

Inputs, Outputs, and Control Terminals

Analog and Digital I/O

• Analog inputs:

  • 0–10 V

  • 0–5 V

  • 0–20 mA

• Digital inputs: 4 programmable inputs

• Outputs:

  • Logic output

  • Relay output (R1A, R1B, R1C)

The flexible I/O configuration allows easy customization and integration into control panels.

Protection and Safety Features

Schneider ATV310HD18N4E is designed with advanced protection mechanisms to ensure motor safety and system reliability:

• Overcurrent and short-circuit protection

• Overvoltage and undervoltage protection

• Motor phase loss protection

• Thermal motor protection (I²t)

• Drive overheating protection

• Safe motor stopping via DC braking

These features help minimize downtime and extend equipment lifespan.

Energy Efficiency and Cost Savings

Schneider ATV310HD18N4E includes energy-saving functions that optimize motor performance based on load conditions:

• Automatic energy optimization

• Reduced power consumption at partial load

• Lower mechanical stress on motors

This results in reduced electricity costs and improved operational efficiency.

Installation, Design, and Environmental Specifications

Mechanical Specifications

• Mounting position: Vertical (±10°)

• Dimensions:

  • Height: 330 mm

  • Width: 180 mm

  • Depth: 191 mm

• Weight: 6.3 kg

• Cooling: Integrated fan

• Protection rating:

  • IP20

  • IP4X on top

Environmental Conditions

• Operating temperature: −10°C to +55°C

• Storage temperature: −25°C to +70°C

• Relative humidity: 5–95% (non-condensing)

• Operating altitude: Up to 1000 m without derating

Compliance and International Standards

Schneider ATV310HD18N4E complies with major international standards:

• IEC / EN 61800-5-1

• IEC / EN 61800-3

• CE certified

• RoHS compliant

This ensures safe operation and suitability for regulated industrial environments.

Typical Industrial Applications of Schneider ATV310HD18N4E

Schneider ATV310HD18N4E is commonly used in:

• Conveyors and material handling systems

• Packaging and printing machines

• Textile machinery

• Pumps and fans

• Compressors and mixers

• Automated production lines

Its compact design and reliability make it ideal for continuous industrial operation.

Why Choose Schneider ATV310HD18N4E from ATCS for Control Systems?

• Get original Schneider ATV310HD18N4E inverters supplied by an authorized industrial distributor in Egypt

• Benefit from expert technical consultation to select the right inverter for your application

• Enjoy reliable stock availability and fast delivery for industrial projects

• Receive professional support before and after sales from an experienced automation team

• Ensure competitive pricing with genuine products and official warranty

Contact ATCS for Control Systems today via WhatsApp to get the best price and technical support for Schneider ATV310HD18N4E
Chat with us on WhatsApp

To explore more in-depth articles about other industrial products with full technical details and applications, discover our complete product guides here.

Frequently Asked Questions (FAQ)

What is the price of Schneider ATV310HD18N4E in Egypt?

The best prices and exclusive offers in Egypt are available through ATCS for Control Systems, with official warranty and professional technical support. Contact us to receive the latest offers and a customized quotation.

Where can I buy Schneider ATV310HD18N4E inverter?

You can buy Schneider ATV310HD18N4E from authorized industrial distributors to ensure original products, official support, and after-sales service.

Is Schneider ATV310HD18N4E suitable for heavy-duty applications?

Yes, Schneider ATV310HD18N4E supports heavy-duty operation up to 18.5 kW, making it suitable for demanding industrial applications.

Does Schneider ATV310HD18N4E support Modbus communication?

Yes, the inverter features built-in Modbus RTU communication via RS-485 for PLC and SCADA integration.

Is Schneider ATV310HD18N4E energy efficient?

Yes, It includes energy-saving control modes that help reduce power consumption and operating costs.

Conclusion

Schneider inverter is a dependable and efficient inverter solution for industrial motor control applications. With strong protection features, flexible communication, and reliable performance, it is an excellent choice for factories and automation systems seeking long-term efficiency and stability.
