The ATS22C14Q is a Schneider Electric Altistart 22 soft starter designed to control the starting and stopping of three-phase asynchronous motors. With a 140 A starter rating and a 230–440 V supply range, it is used in applications such as pumps, fans, compressors and material-handling equipment.
By controlling motor starting torque and limiting starting current, the ATS22C14Q can help reduce mechanical stress during startup. Its built-in bypass and Modbus communication also make it suitable for a range of industrial motor-control systems.
Download the ATS22C14Q datasheet (PDF)
ATS22C14Q specifications
| Specification | Details |
|---|---|
| Product range | Schneider Electric Altistart 22 |
| Product type | Soft starter for asynchronous motors |
| Supply phases | Three-phase |
| Rated supply voltage | 230–440 V |
| Starter current rating | 140 A for standard applications in line connection |
| Factory setting current | 131 A |
| Motor power, line connection | 37 kW at 230 V; 75 kW at 400–440 V |
| Control circuit supply | 230 V AC, 50/60 Hz |
| Bypass | Internal bypass |
| Communication | Modbus via serial RJ45 connection |
| Degree of protection | IP00 |
Motor power depends on the supply voltage and connection method. Schneider Electric also lists ratings up to 110 kW at 400–440 V for a motor-delta connection. Confirm the motor nameplate, wiring arrangement and manufacturer’s selection tables before choosing a starter. See Schneider Electric product information.
How the Altistart 22 soft starter works
A soft starter controls the voltage supplied to a motor during startup and stopping. This lets the motor accelerate more gradually than it would with direct-on-line starting, helping reduce sudden torque and mechanical shock to connected equipment.
The ATS22C14Q uses torque control, with starting current limited to 3.5 times the rated motor current. After startup, its internal bypass supports operation while reducing heat dissipation in the starter. The unit also provides Modbus communication for integration with compatible control systems.
Typical ATS22C14Q applications
The ATS22C14Q is suited to three-phase motor applications where controlled starting and stopping are needed. Common examples include:
- Centrifugal and piston pumps
- Fans and blowers
- Screw compressors
- Conveyors and material-handling equipment
For systems that need the motor to run at adjustable speeds, a variable frequency drive (VFD) may be a better fit. A soft starter controls the start and stop; it does not provide ongoing speed control like a VFD.
What to check before selecting ATS22C14Q
Before specifying this model, check the motor’s rated current and voltage, the starter’s connection method, and the load’s starting requirements. Match the starter to the application using the manufacturer’s sizing guidance; motor kilowatts alone are not enough to confirm compatibility.
Also check the control supply and the installation enclosure. IP00 means the starter itself has no protective enclosure, so it must be installed in a suitable electrical panel with protection appropriate to the installation environment.
Schneider Electric lists ATS430C14S6 as a recommended replacement for ATS22C14Q on some regional product pages. Check current availability in Egypt and verify the replacement’s suitability for the specific motor and application before ordering. View Schneider Electric’s product information.
Frequently asked questions
What is the ATS22C14Q?
It is a 140 A Schneider Electric Altistart 22 soft starter for three-phase asynchronous motors.
What is the maximum motor power?
The listed line-connection ratings are 37 kW at 230 V and 75 kW at 400–440 V. Schneider Electric also lists up to 110 kW for a 400–440 V motor-delta connection. Always confirm the motor current, connection and application requirements against the manufacturer’s documentation.
Does the ATS22C14Q have a built-in bypass?
Yes. It has an internal bypass.
Can the ATS22C14Q control motor speed?
No. It manages motor starting and stopping. Use a VFD when the application requires adjustable running speed.
Where can I get the ATS22C14Q datasheet?
Download the ATS22C14Q datasheet from Schneider Electric. For a durable download link on your website, upload the PDF to the ATCS media library and link the article’s datasheet button to that file.
For ATS22C14Q availability, quotation or application guidance, contact ATCS Egypt.
